The parking barrier lock is a smart device suitable for on-street parking, commercial spaces, and shared parking spaces, providing an efficient solution for urban parking management.
The lock automatically engages and charges once the vehicle is parked. Drivers can quickly pay and be released by scanning a QR code, enabling 24/7 unattended operation. Its high-strength materials and intelligent anti-pressure design prevent payment evasion and parking space hogging, while also protecting the vehicle's chassis, significantly improving parking space utilization and management efficiency.
Main Benefits
Advantage 1: High-Level Water Resistance
IP68 dustproof and waterproof rating, remains fully operational and maintains stable performance after daily immersion tests, flooding from natural disasters, or silt intrusion.
Advantage 2: High Load-Bearing Capability
Operates normally under vehicle loads. Up to 4 tons when the flap is raised, and up to 10 tons when the flap is lowered.
Advantage 3: Extremely Thin Design
Continuous innovation and optimization have reduced the motor, reducer, screw, linkage, control system, and battery components to within 6.6 cm, reaching the mechanical component space limitand making it the thinnest on the market.
Advantage 4: Extended Battery Life
Uses advanced energy-savingtechnology to deliver strong performance while minimizing power consumption, achieving up to 300 days of continuous operation.
Parameter:
| Item | Ground |
| Type - Left | |
| Battery Specifications | Lithium Battery Pack DC14.8V/14.5Ah |
| Operating Voltage | DC12V~18V |
| Motor Specs | DC12V/30W |
| Communication Method | 4G + Bluetooth |
| Detection Mode | Dual-mode: |
| Radar + Geomagnetic / Radar + Ground Sensor | |
| Standby Time | ≥10 months |
| Voice Prompts | TTS (Text-to-Speech) |
| Speaker Power | 2W |
| Lift Time | ≤5 seconds |
| Drop Time | ≤5 seconds |
| Water Level Detection | Non-contact |
| Protection Level | IP68 |
| Operating Temperature | -25°C to +65°C |
| Environmental Humidity | ≤90% |
| Atmospheric Pressure | 86~106 kPa |
| Dimensions | 790mm × 330mm × 55mm |
| Max plate Height | 205mm |
| Max Plate Angle | 75° |
| Max Load Capacity When Lowered | 10 tons /10,000 kg |
| Service Life | 10 years |
